35kV step-up transformer winding adopts high conductivity copper conductor, high and low voltage are all copper windings. The iron core adopts domestic high-quality high-permeability oriented silicon steel sheet, the iron core is firmly bound and clamped, and has good insulation. All fasteners are treated with anti-loosening. The transformer body adopts a new insulation structure, and the transformer has strong short-circuit resistance. The transformer is equipped with a temperature controller. In addition to displaying the three-phase winding temperature during operation, it also has control functions such as fault alarm, high temperature sound and light alarm, and overtemperature trip alarm. The product is equipped with a fan, which can effectively protect the safe operation of the transformer.

Performance characteristics

1. Low loss, energy saving and environmental protection.

2. Good technical and economic performance.

3. Low noise.

4. High efficiency and energy saving, can save a lot of power consumption and operating costs, social benefits are significant.

5. Good moisture-proof performance, fire retardant, no pollution, maintenance-free, easy to install.
